Ntsev Fog Chambers
Lub npe: Ntsev pos huab chav
Khoom siv: iav Fiber
Daim ntawv thov: ntsev Corrosion Test
Humidity Range: 30% ~ 98% RH
Temp. Ntau: +10 degree - +90 degree
Txau hom: Nruam / Periodic
Controller: PID maub los
Hauj lwm lawm
LIB ntsev pos chambers yog simulate lub dispersion system muaj li ntawm me me tee dej uas muaj ntsev nyob rau hauv cov huab cua.
Video
Parameter
|
Qauv |
S-150 |
S-250 |
S-750 |
S-010 |
S-016 |
S-020 |
|
Internal qhov ntev (mm) |
590*470*400 |
1000*640*500 |
1100*750*500 |
1000*1300*600 |
900*1600*720 |
1000*2000*800 |
|
Zuag qhia tag nrho qhov ntev (mm) |
1460*760*1140 |
1850*960*1350 |
1950*1030*1350 |
2000×1300×1600 |
2300×1300×1700 |
2700×1300×1900 |
|
Sab hauv Volume (L) |
110 |
320 |
410 |
780 |
1030 |
1600 |
|
Qhov kub thiab txias |
Ambient - +60 degree |
|||||
|
Kub Fluctuation |
± 0.5 degree |
|||||
|
Kub Deviation |
± 2 0 degree |
|||||
|
Humidity Range |
95% ~ 98% RH |
|||||
|
Ntsev Fog Deposition |
1-2ml / 80cm2 · h |
|||||
|
Hom tshuaj tsuag |
Nruam / Periodic |
|||||
|
Ntsev Fog Sau |
Fog collector thiab ntsuas huab cylinder |
|||||
|
Cua Preheating |
Saturated cua chim |
|||||
|
Txau System |
Atomizer ntauwd thiab Spray nozzles |
|||||
|
Tus tswj |
PID tswj |
|||||
|
Cov cuab yeej kev nyab xeeb |
Humidifier Qhuav-combustion Protection; Kev tiv thaiv kub dhau; Kev tiv thaiv dhau tam sim no; Kev tiv thaiv dej tsis txaus; Ntiaj teb leakage Protection |
|||||
|
Khoom siv |
Cov iav fiber reinforced yas |
|||||
|
Standard Configuration |
6 round bars thiab 5 V-zoo li tus grooves |
|||||
Paub meej Tsim
 |
 |
 |
| Txau ntauwd | Cov Khoom Muag | Tus tswj |
 |
 |
Yam ntxwv
●Txau ntau tus sib npaug
Cov dej ntsev nplawm cov cuab yeej ua rau cov dej ntsev ntau dua
●Ib puag ncig tus phooj ywg kev kho cua sov rwb thaiv tsev
Cov txheej txheej rwb thaiv tsev nyob hauv qab ntawm chav sim yog ua los ntawm cov av nplaum, uas tuaj yeem ua kom sov rwb thaiv tsev zoo thiab yog ib puag ncig zoo.
●Ntsev tov mixing system
Lub tshuab nqus dej ntsev yog nruab rau hauv lub tank dej ntsev, uas tuaj yeem tsis tsuas yog do cov dej ntsev kom muaj kev sib luag, tab sis kuj ua kom sov cov dej ntsev kom ruaj khov pH.
